Key Points:
| MRC Rated Capacity | 1100 lb |
| Voltage | 1 Phase 110~120V 60Hz |
| Speed (f/m) / min | 20 ft / 6 mt |
| Load Chain Type | FEC G80 Japan |
| Control Included | Wireless Juuko HS-K200NC2Q |
Key Features:
- H2/M3/1Bm/Class A duty cycle classification applies to lifting equipment used in light manufacturing, service, and maintenance tasks in machinery workshops, operating up to 7.5 minutes per hour with a maximum of 75 starts, a 12.5% operational time factor (K = 0.65), and a life expectancy of 2,500 hours
- Heavy Duty Control System Powered by Yes a powerful 1400 Motor with IP54IEC Motor Protection
Technical Specifications:
| MRC Rated Capacity | 1100 lb | Motor Brake | Yes |
| Number of Speeds | 1 Speed | Load Chain Type | FEC G80 Japan |
| Duty Class | H2/M3/1Bm/Class B | Load Chain Size | 6.3 mm x 19.1 mm |
| Standard Lifting Height | 80 ft / 24 m | Rig Chain Falls / Lines | 1 |
| Voltage | 1 Phase 110~120V 60Hz | Chain Length (ft) | 80 ft |
| Speed (f/m) / min | 20 ft / 6 mt | Control Range | 150 ft Wireless |
| Control Voltage | 110 V (Optional) | FCC Cert ID | RN489896162-B0129 |
| Control Included | Wireless Juuko HS-K200NC2Q | Total Power Watts | 1400 W |
| Contactor Brand | Yes | IEC Motor Protection | IP54 |
| Motor Power | 1400 | Warranty | 1 Year |
| Motor AMP | 10 A | Emergency Stop | Yes |
