Key Points:
| MRC Rated Capacity | 2200 lb / 1000 kg |
| Voltage | 1 Phase 110~120V 60Hz |
| Duty Class | H2/M3/1Bm/Class B |
| Load Chain Type | FEC G80 Japan |
| Number of Speeds | 1 Speed |
| Control Included | Wireless JUUKO HS-K200NC2Q |
Key Features:
- H2/M3/1Bm/Class A duty cycle classification applies to lifting equipment used in light manufacturing, service, and maintenance tasks in machinery workshops, operating up to 7.5 minutes per hour with a maximum of 75 starts, a 12.5% operational time factor (K = 0.65), and a life expectancy of 2,500 hours
- Heavy Duty Control System Powered by Yes a powerful 1.8 kW Motor with IP54IEC Motor Protection
- Standards Compliance and or Certifications ASME HST-1 , ASME B30.16 , EN14492-2 , EN60204-32 , ,
Technical Specifications:
| MRC Rated Capacity | 2200 lb / 1000 kg | Rig Chain Falls / Lines | 1 |
| Number of Speeds | 1 Speed | Chain Length (ft) | 12 ft |
| Duty Class | H2/M3/1Bm/Class B | Control Range | 300 ft |
| Standard Lifting Height | 16 ft / 5 m | FCC Cert ID | RN489896162-B0129 |
| Voltage | 1 Phase 110~120V 60Hz | Receiver Power Supply | 110V |
| Speed (f/m) / min | 13.2 ft / 4m | Buttons | Up, Down Emergency Stop |
| Control Voltage | 110 V | Total Power Watts | 1800W |
| Control Included | Wireless JUUKO HS-K200NC2Q | Noise Level | 70 dB |
| Contactor Brand | Yes | Humidity | <85% |
| Motor Power | 1.8 kW | Temperature | -4 ~ 104° F / -20 ~ 40° C |
| Motor AMP | 13 | IEC Motor Protection | IP54 |
| Motor Insulation Grade | F | Standards Compliance | ASME HST-1 , ASME B30.16 , EN14492-2 , EN60204-32 |
| Motor Brake | Yes | Warranty | 3 Year |
| Load Chain Type | FEC G80 Japan | Emergency Stop | Yes |
| Load Chain Size | 7.1×20.2 mm |
