Key Points:
| MRC Rated Capacity | 2200 lb / 1000 kg |
| Voltage | 3 Phase 208~240/440~480V 50/60Hz |
| I-Beam Width Range | 2~6 in / 52~153 mm |
| Minimum Turn Radius | 2.62 ft / 0.8 m |
| Trolley Speed /min | 43 ft / 13 m @ 60 HZ | 36 ft / 11 @ 50 HZ |
| Standards Compliance | ASME B30.17 |
Key Features:
- Standards Compliance and or Certifications ASME B30.17 , ,
Technical Specifications:
| MRC Rated Capacity | 2200 lb / 1000 kg | Minimum Turn Radius | 2.62 ft / 0.8 m |
| Voltage | 3 Phase 208~240/440~480V 50/60Hz | Standards Compliance | ASME B30.17 |
| Total Power Watts | 0.4 kW | Warranty | 3 Year |
| Trolley Speed /min | 43 ft / 13 m @ 60 HZ | 36 ft / 11 @ 50 HZ | T Trolley Motor Width | 9.09 in / 231 mm |
| I-Beam Width Range | 2~6 in / 52~153 mm | R Trolley Cover Width | 6 in / 142 mm |
