Key Points:
| MRC Rated Capacity | 1 ton |
| Voltage | 3 Phase 220~240/440~480V 60Hz |
| End-Truck Length | 2500 mm |
| Duty Class | H4/M5/2m/Class D |
| Standards Compliance | ASME / CMAA / Nch |
Key Features:
- H4/M5-M6/2m-3m/Class C-Class D duty cycle classification applies to lifting equipment used in high-volume heavy load handling, such as steel handling and manufacturing operations, or in lighter-load automatic cycles like heat treatment, operating up to 30 minutes per hour with a maximum of 300 starts, a 50% operational time factor (K = 0.65), and a life expectancy of 10,000 hours.
- Standards Compliance and or Certifications ASME / CMAA / Nch , ,
Technical Specifications:
| MRC Rated Capacity | 1 ton | End-Truck Length | 2500 mm |
| Number of Speeds | 1 Speed – Optional Variable Speed | Max. Span | 70 ft |
| Duty Class | H4/M5/2m/Class D | I-Beam Width Range | 110 – 300 mm (4.33 – 11.8 in) |
| Voltage | 3 Phase 220~240/440~480V 60Hz | Material | Steel |
| Speed (f/m) / min | 66 ft | IEC Motor Protection | IP54 |
| Control Included | Not Included. Optional single Speed, 2 Speed and Variable Speed | Standards Compliance | ASME / CMAA / Nch |
| Motor Brake | Yes | Warranty | 3 Year |
| Dynamic Brake | Only with VFD Optional | Variable Fequency Driver | Optional 1.5 Kw |
| Total Power Watts | 0.25Kw x 4 |
