The DWE7491X 10 in. Jobsite Table Saw with Scissor Stand has a 15 Amp motor and 32-1/2 in. rip capacity to allow cutting of large and hardwood materials. Features tool-free guarding component adjustments and fast, accurate fence adjustments. Scissor stand designed for easy set up and breakdown with excellent stability.
FEATURES & SPECS
FEATURES
- Rack & Pinion Telescoping Fence System Make fence adjustments fast, smooth and accurate
- 32-1/2 in. rip capacity easily cuts a variety of larger shelving and trim materials
- Two position flip-over rip fence allows for narrow rip cuts and material support
- Site-Pro modular guarding system allows for tool-free adjustments of guarding components appropriate for each application
- 2-1/2 in. Dust Collection Port easily connects to a vacuum for efficient dust extraction
- Onboard storage system provides easy access to the Blade Guard Assembly, fence, riving knife, miter gauge, wrenches, push stick, and cord wrap when not in use.
- Folding scissor stand designed for easy set up and breakdown with excellent stability
- 15 amp Motor quickly rips through hardwoods with ease
- Telescoping fence rails retract to create a small, portable package
- 3-1/8 in. depth-of-cut at 90 and 2-1/4 in. at 45
SPECIFICATIONS
- AMPS 15 AMPS
- ARBOR SIZE 5/8 IN
- BLADE DIAMETER 10″
- DEPTH OF CUT AT 45° 2-1/4 IN
- DEPTH OF CUT AT 90° 3-1/8 IN
- DUST PORT DIAMETER 2-1/2 IN
- MAX RIP TO LEFT OF BLADE 22 IN
- MAX RIP TO RIGHT OF BLADE 32-1/2 IN
- MAX WIDTH OF DADO 13/16 IN
- NO LOAD SPEED 4800 RPM
- TOOL HEIGHT 30.25 IN
- TOOL LENGTH 26.375 IN
- TOOL WEIGHT 87 LBS
INCLUDES
- 10 in. 24-Tooth Carbide Blade
- Scissor Stand
- Push Stick
- Miter Gauge
- Rip Fence
- 2x Blade Wrenches
- Blade Guard Assembly
