Key Points:
| MRC Rated Capacity | 500 kg / 1100 lbs |
| Voltage | 1 Phase 220~240V 50/60Hz |
| Speed (f/m) / min | 10m/min @ 1 linea | 5 m/min @ 2 lineas |
| Duty Class | H2/M3/1Bm/Class B |
| Standards Compliance | Intertek 4006091 , UL N 1340, CAN/CSA C22.2 , EN14492-2 , EN60204-32 |
Key Features:
- Standards Compliance and or Certifications Intertek 4006091 , UL N 1340, CAN/CSA C22.2 , EN14492-2 , EN60204-32 , ,
Technical Specifications:
| MRC Rated Capacity | 500 kg / 1100 lbs | Wire Rope Included | ø4.3 mm x 12 m |
| Number of Speeds | 1 Speed | FCC Cert ID | OFNF21 |
| Duty Class | H2/M3/1Bm/Class B | Noise Level | 71 dB |
| Voltage | 1 Phase 220~240V 50/60Hz | Humidity | <85% |
| Speed (f/m) / min | 10m/min @ 1 linea | 5 m/min @ 2 lineas | Temperature | -4°~104° F / -20°~40° C |
| Motor Power | 1450 W | IEC Motor Protection | IP40 |
| Motor Insulation Grade | B | Standards Compliance | Intertek 4006091 , UL N 1340, CAN/CSA C22.2 , EN14492-2 , EN60204-32 |
| Motor Brake | YES | Warranty | 1 Year |
