Key Points:
| MRC Rated Capacity | 2200 lbs / 1000 kg |
| Voltage | 1 Phase 110~120V 60Hz |
| Speed (f/m) / min | 33 ft/10m @1line | 16ft/5m @2line |
| Duty Class | H2/M3/1Bm/Class B |
| Standards Compliance | Intertek 4006091 , UL N 1340, CAN/CSA C22.2 , EN14492-2 , EN60204-32 |
Key Features:
- Standards Compliance and or Certifications Intertek 4006091 , UL N 1340, CAN/CSA C22.2 , EN14492-2 , EN60204-32 , ,
Technical Specifications:
| MRC Rated Capacity | 2200 lbs / 1000 kg | Wire Rope Included | ø7/32 in x 38 ft | ø5.58 mm x 12 m |
| Number of Speeds | 1 Speed | FCC Cert ID | OFNF21 |
| Duty Class | H2/M3/1Bm/Class B | Noise Level | 71 dB |
| Voltage | 1 Phase 110~120V 60Hz | Humidity | <85% |
| Speed (f/m) / min | 33 ft/10m @1line | 16ft/5m @2line | Temperature | -4°~104° F / -20°~40° C |
| Motor Power | 1600 W | IEC Motor Protection | IP40 |
| Motor AMP | 12.5 AMP | Standards Compliance | Intertek 4006091 , UL N 1340, CAN/CSA C22.2 , EN14492-2 , EN60204-32 |
| Motor Insulation Grade | B | Warranty | 1 Year |
| Motor Brake | YES |
