Key Points:
| MRC Rated Capacity | 20000 lb |
| Voltage | Battery Power 12 VDC |
| Wire Rope Included | Steel ø1/2 in x 72 ft | ø13 mm x 22 m |
| Speed (f/m) / min | 3.4~17 ft / 1~5 m |
| Control Included | Wireless and Wired |
| Warranty | 1 Year |
Technical Specifications:
| MRC Rated Capacity | 20000 lb | Transmission / Reducer Type | 4-Stage Planetary |
| Number of Speeds | 1 Speed | Free Spooling Clutch Type | Sliding Ring Gear |
| Voltage | Battery Power 12 VDC | Gear Ratio | 544:1 |
| Speed (f/m) / min | 3.4~17 ft / 1~5 m | Electric Control Box | Reverse Solenoid Control Box |
| Control Voltage | 12 V | Accessories | Control and Installation Hardware |
| Control Included | Wireless and Wired | IEC Motor Protection | IP67 |
| Motor Model | DC Series Wound Motor | Warranty | 1 Year |
| Motor AMP | 450 AMP | Fairlead | Included |
| Drum Brake | In-Drum Automatic Brake | Number of Layers | 4 |
| Wire Rope Included | Steel ø1/2 in x 72 ft | ø13 mm x 22 m | Drum DL Length | 228 mm |
| 1st Layer MRC Capacity | 20000 lbs | Drum BD Barrel Diameter | 89 mm |
| FCC Cert ID | 2ASYP-DW12K |
