Key Points:
| MRC Rated Capacity | 3500 lb |
| Voltage | 1 Phase 220~240V 50/60Hz |
| Speed (f/m) / min | 22~34 ft / 6~10 m |
| Number of Speeds | 1 Speed |
| Control Included | Wired remote control |
Key Features:
- H2/M3/1Bm/Class A duty cycle classification applies to lifting equipment used in light manufacturing, service, and maintenance tasks in machinery workshops, operating up to 7.5 minutes per hour with a maximum of 75 starts, a 12.5% operational time factor (K = 0.65), and a life expectancy of 2,500 hours
- Control System Powered By High Performance Contactors with a powerful 2.24 kW / 3 HP Motor with IP55IEC Motor Protection
- Standards Compliance and or Certifications ASME/ANSI B30.7,10 / AWS D14.3 / RR-W-410E / ISO 2232 , ,
Technical Specifications:
| MRC Rated Capacity | 3500 lb | 1st Layer MRC Capacity | 3800 lb / 1750 kg |
| Number of Speeds | 1 Speed | Electric Control Box | Included |
| Standard Lifting Height | Up to 328 ft / 100 m | Humidity | <85% |
| Voltage | 1 Phase 220~240V 50/60Hz | IEC Electric Enclosure Protection | IP65 |
| Speed (f/m) / min | 22~34 ft / 6~10 m | IEC Motor Protection | IP55 |
| Made in | Taiwan | Standards Compliance | ASME/ANSI B30.7,10 / AWS D14.3 / RR-W-410E / ISO 2232 |
| Control Voltage | 24V | Warranty | 3 Year |
| Control Included | Wired remote control | Drum DL Length | 345 mm |
| Motor Model | Electric AC | Drum FD Flange Diameter | ø305 mm |
| Wire Rope Included | ø7/16 in x 328 ft | ø11.1 mm x 100 m | Drum BD Barrel Diameter | ø140 mm |
