Key Points:
| MRC Rated Capacity | 500 lb |
| Voltage | 1 Phase 110~120V 60Hz |
| Duty Class | H1/M2/1Cm/Class A |
| Load Chain Type | FEC G80 Japan |
| Number of Speeds | 1 Speed |
| Control Included | Pendant Control |
Key Features:
- H1/M2/1Cm/- duty cycle classification describes lifting equipment used infrequently for installing and maintaining heavy equipment, operating up to 7.5 minutes per hour with a maximum of 75 starts, a 12.5% operational time factor (K = 0.65), and a life expectancy of 1,250 hours.
- Heavy Duty Control System Powered by a powerful 200 Watts Motor with IP40IEC Motor Protection
Technical Specifications:
| MRC Rated Capacity | 500 lb | Motor Brake | Yes |
| Number of Speeds | 1 Speed | Load Chain Type | FEC G80 Japan |
| Duty Class | H1/M2/1Cm/Class A | Load Chain Size | 4 mm x 12 mm |
| Standard Lifting Height | Up to 12 ft / 3.65 m | Rig Chain Falls / Lines | 1 |
| Voltage | 1 Phase 110~120V 60Hz | Chain Length (ft) | 12 ft |
| Speed (f/m) / min | 12.5 ft per min | Noise Level | 75 dB |
| Control Voltage | 110V | Humidity | <85% |
| Control Included | Pendant Control | Temperature | -4 ~ 104° F / -20 ~ 40° C |
| Motor Power | 200 Watts | IEC Motor Protection | IP40 |
| Motor AMP | 4 | Warranty | 1 Year |
| Motor Insulation Grade | B | Emergency Stop | YES |
