Key Points:
| MRC Rated Capacity | 551 lb / 250 kg |
| Voltage | 1 Phase 220~240V 50/60Hz |
| Number of Speeds | 1 Speed |
| Duty Class | H1/M2/1Cm/Class A |
| Control Included | Pendant Control and Optional Wireless F21 |
Key Features:
- H1/M2/1Cm/- duty cycle classification describes lifting equipment used infrequently for installing and maintaining heavy equipment, operating up to 7.5 minutes per hour with a maximum of 75 starts, a 12.5% operational time factor (K = 0.65), and a life expectancy of 1,250 hours.
- Heavy Duty Control System Powered By a powerful 1300 W Motor with IP54IEC Motor Protection
- Standards Compliance and or Certifications ASME B30.16 , ,
Technical Specifications:
| MRC Rated Capacity | 551 lb / 250 kg | Motor Brake | YES |
| Number of Speeds | 1 Speed | Wire Rope Included | ø3/16 in | ø4.5 mm |
| Duty Class | H1/M2/1Cm/Class A | Noise Level | 71 dB |
| Standard Lifting Height | 200 ft / 60 m | Humidity | <85% |
| Voltage | 1 Phase 220~240V 50/60Hz | Temperature | -4°~104° F / -20°~40° C |
| Speed (f/m) / min | 49 ft / 15 m | IEC Motor Protection | IP54 |
| Control Included | Pendant Control and Optional Wireless F21 | Standards Compliance | ASME B30.16 |
| Motor Model | Squirrel Cage Induction Motor | Warranty | 1 Year |
| Motor Power | 1300 W | Emergency Stop | YES |
| Motor Insulation Grade | B |
