Key Points:
| MRC Rated Capacity | 660 lb / 300 kg |
| Voltage | 1 Phase 110~120V 60Hz |
| Duty Class | H1/M2/1Cm/Class A |
| Load Chain Type | G80 |
| Number of Speeds | 1 Speed |
| Control Included | Wireless F21 / Optional Pendant Control |
Key Features:
- H1/M2/1Cm/- duty cycle classification describes lifting equipment used infrequently for installing and maintaining heavy equipment, operating up to 7.5 minutes per hour with a maximum of 75 starts, a 12.5% operational time factor (K = 0.65), and a life expectancy of 1,250 hours.
- Heavy Duty Control System Powered by HSIN DA 20 AMP a powerful 500 Watts Motor with IP54IEC Motor Protection
- Standards Compliance and or Certifications , ,
Technical Specifications:
| MRC Rated Capacity | 660 lb / 300 kg | Load Chain Type | G80 |
| Number of Speeds | 1 Speed | Load Chain Size | 13/64 in | 5 mm |
| Duty Class | H1/M2/1Cm/Class A | Rig Chain Falls / Lines | 1 |
| Standard Lifting Height | 10 ft / 3 m | Chain Length (ft) | 10 ft / 3 m |
| Voltage | 1 Phase 110~120V 60Hz | FCC Cert ID | OFNF21 |
| Speed (f/m) / min | 10 ft / 3 m | Gear Ratio | 119:1 |
| Control Voltage | 2 X AA Battery | Noise Level | 80 dB |
| Control Included | Wireless F21 / Optional Pendant Control | Humidity | <85% |
| Contactor Brand | HSIN DA 20 AMP | Temperature | -4 ~ 104° F / -20 ~ 40° C |
| Motor Power | 500 Watts | IEC Motor Protection | IP54 |
| Motor AMP | 5.12 | Warranty | 1 Year |
| Motor Insulation Grade | B | Emergency Stop | Yes |
| Motor Brake | Yes |
