Key Points:
| MRC Rated Capacity | 840 lb |
| Voltage | 1 Phase 220~240V 50/60Hz |
| Speed (f/m) / min | 50~68 ft / 15~20 m |
| Number of Speeds | 1 Speed |
Key Features:
- H2/M3/1Bm/Class A duty cycle classification applies to lifting equipment used in light manufacturing, service, and maintenance tasks in machinery workshops, operating up to 7.5 minutes per hour with a maximum of 75 starts, a 12.5% operational time factor (K = 0.65), and a life expectancy of 2,500 hours
- Control System Powered By High Performance Contactors with a powerful 1.1 kW Motor with IP55IEC Motor Protection
- Standards Compliance and or Certifications ASME B30.7 / B30.10 / ANSI-AWS , ,
Technical Specifications:
| MRC Rated Capacity | 840 lb | Wire Rope Included | ø1/4 in x 98 ft | ø6.3 mm x 30 m |
| Number of Speeds | 1 Speed | 1st Layer MRC Capacity | 844 lb / 383 kg |
| Standard Lifting Height | 100 ft / 30 m | IEC Electric Enclosure Protection | IP65 |
| Voltage | 1 Phase 220~240V 50/60Hz | IEC Motor Protection | IP55 |
| Speed (f/m) / min | 50~68 ft / 15~20 m | Standards Compliance | ASME B30.7 / B30.10 / ANSI-AWS |
| Control Voltage | 110V | Warranty | 1 Year |
| Motor Model | Electric AC | Drum DL Length | 139 mm |
| Motor Power | 1.1 kW | Drum FD Flange Diameter | ø142 mm |
| Drum Brake | NO | Drum BD Barrel Diameter | ø94 mm |
