Bailey Transformer Low-volt Light System – 143820

This quality transformer is a very nice universal transformer from 0-70W which, when combined with the dimming installation, guarantees an excellent dimming effect.

Specifications

Type of transformer : Electronic transformer
Safety transformer : No
Input voltage (V) : 220 V to 240 V
Output voltage (V) : 12 V to 12 V
Power (W) : 0 W to 45 W
No dim function : No
Dimming 0-10 V : No
Dimming 1-10 V : No
Dimming DALI : No
Dimming DSI : No
Dimming DMX : No
Dimming potentiometer (integrated) : No
Dimming GPRS : No
Dimming LineSwitch : No
Dimming manufacturer’s proprietary system : No
Dimming mains voltage modulation : No
Dimming phase cut-off : Yes
Dimming phase cut-on : Yes
Dimming programmable : No
Dimming RF : No
Dimming Sine Wave Reduction : No
Dimming Touch and Dim : No
Dimming Zigbee : No
Dimming with push-button : No
Degree of protection (NEMA) : Other
Connection type primary side : Screw connection
Connection type secondary side : Screw connection
Surface-mounted : No
Built-in : No
Material : Plastic
Color : Grey
Short-circuit protected : No
Overload protection : No
Overtemperature protection : No
With secondary automatic circuit breaker : No
Number of output positions (pairs) : 1
Length (mm) : 113
Width (mm) : 44
Height (mm) : 28
Degree of protection (IP) : IP20
Compatible with Apple HomeKit : No
Compatible with Google Assistant : No
Compatible with Amazon Alexa : No
IFTTT support available : No
