Carlo Gavazzi SPD24 DC power supply unit. (wxdxh: 40.5x114x90mm), 1st Secondary voltage 24V. Voltage type supply voltage AC/DC. Nominal supply voltage AC 50 Hz 85-264V. Max. output current 12.5A, power output 60W. Nominal output voltage 124V. Carrier rail mounting possible.
Specifications
Voltage type of supply voltage : AC/DC
1st secondary output voltage at DC (V) : 24 V to 24 V
Max. output current 1 (A) : 2.5
Secondary voltage adjustable : Yes
Nominal value output voltage 1 (V) : 24
Nominal value output current 1 (A) : 2.5
Rated voltage AC (V) : 85 V to 264 V
Rated voltage (AC 60 Hz) (V) : 85 V to 264 V
Rated voltage DC (V) : 90 V to 375 V
Electrical connection : Screw connection
Output voltage stabilized : Yes
Power consumption (VA) : 8.8
Power output (W) : 60
Stabilized : Yes
Short-circuit-proof : Yes
Degree of protection (IP) : IP20
Refurbished : No
Modular version : No
Direct mounting possible : No
Wall mounting possible : No
Rail mounting possible : Yes
Performance level (EN ISO 13849-1) : Level a
Built-in height (mm) : 90
Built-in width (mm) : 40.5
