ELEQ TQ50-E Current Transformer 250/1A | 4Q5R10

Eleq TQ50E current measuring transformer. Primary measuring current in 250A. Secondary rated current 1A. Secondary (measuring), apparent power 0.5VA. Version overshooting current measurement transformer. Accuracy class 1. Height opening 42mm. Width opening 18mm. Opening diameter 42mm. 1 primary inputs.

Specifications

Primary rated current (A) : 250
Secondary rated apparent power (VA) : 0.5
Secondary rated current (A) : 1
Number of phases : 1
Secondary connection : Screw connection
Output voltage : No
Calibrated : No
Conductor feedthrough : 42 x 42 mm
Number of primary inputs : 1
Height opening (mm) : 42 mm to 42 mm
Model : Attachable current transformer
Width opening (mm) : 18 mm to 18 mm
Opening diameter (mm) : 42
Snap mounting : No
With copper rail : No
