Power supply switch. Standby loss of only 0.2 Watts Other switching power supplies may be required if the series14 bus system’s total power consumption exceeds 8W. They may not all be connected simultaneously, but each feeds a set of actuators that are separated by a divider bridge on FSNT14. The package includes 1 isolation bridge TB14 1 DE and 1 sweater 1.5 TE. A spacer DS14 is also included.
Specifications
Voltage type of supply voltage : AC
1st secondary output voltage at DC (V) : 12 V to 12 V
Max. output current 1 (A) : 1
Secondary voltage adjustable : No
Nominal value output voltage 1 (V) : 12
Rated voltage AC (V) : 230 V to 230 V
Electrical connection : Screw connection
Output voltage stabilized : Yes
Power output (W) : 12
Stabilized : Yes
Short-circuit-proof : Yes
Degree of protection (IP) : IP20
Refurbished : No
Modular version : Yes
Wall mounting possible : No
Rail mounting possible : Yes
Built-in height (mm) : 58
Built-in width (mm) : 18
Width in number of modular spacings : 1
