EMAX 115V 10 Amp 5 Micron 30 CFM Coalescing Filter Electric Industrial Refrigerated Air Dryer – EDRCF1150030

Product Features & specs :

EMAX EDRCF1150030 115V 10 Amp 5 Micron 30 CFM Coalescing Filter Electric Industrial Refrigerated Air Dryer

Details

Our EMAX air dryer is the only energy efficient dryer systems with aluminum refrigerated air inner cooler. The air is filtered of all solid particles 0.01 micron and larger. Clean, dry compressed air leaving the dryer minimizes maintenance and repair and also reduces internal dryer contamination. We designed them with Non-corrosive inner and after cooler. Our dryers feature stainless steel heat exchanger for maximum dryer life and less maintenance. Emax Air dryers are UL-CSA approved scroll compressor & electric system for high efficiency and durability. They feature adjustable hot bypass for complete dryer function in low and high CFM flow preventing dryer freeze up.

Features:

• Purifies compressed air by chilling to condense moisture

• Condensate is drained carrying oil and dirt partials away from the air

• Auto drain system – eliminates the need for daily maintenance

• Refrigerant pressure – gauge clearly monitors performance of dew point temp (models under 400 CFM)

• PLC Display (models 400 CFM and above)

• Outlet air baffle heater – prevents condensation on outlet air piping

• Heavy duty steel cabinet

• Trouble free operation refrigerated air inlet inner cooler for high temp cooling

• Top mounted condenser and fan motor

• Environmentally friendly 134A refrigerant

What’s Included:

• 30CFM 115V Refrigerated Air Dryer – EDRCF1150030

Air Inlet Size (Main)

1/2 in

Air Inlet Size (Outlet)

1/2 in

Construction

Steel

Type

Air Dryer

Flow Rate (SCFM)

30

Operating Pressure (PSI)

230

Operating Temperature (Max.)

140 Degrees Fahrenheit

Material

Steel

Length

14.53 in.

Width

14.65 in.

Height

27.81 in.

Weight

77.16 lbs.
