Bürkert indirect operating 2/2-way solenoid valve with DN 50 flange and 230V AC (alternating current) coil. The valve has a cast iron (GG25) housing with EPDM sealing and an orifice size of 50 mm. The circuit function of the solenoid valve is normally closed, which means the valve opens when voltage is applied. However, the function can easily be changed between NC and NO by rotating the pilot valve on the top side by 180 degrees. This model is media separated and can therefore be used for slightly contaminated and aggressive media. The cast iron housing is suited for neutral fluids. The EPDM (ethylene propylene diene monomer rubber) sealing is suited for neutral fluids and many chemicals, but it has poor resistance to oils and fats. Consult our chemical resistance chart to verify compatibility of housing and seals with the medium. You can separately adjust the opening and closing time of the valve with set screws, for example to prevent water hammer. Energy efficient design for a long product lifecycle.
Important advantages
- Can be used with slightly contaminated or aggressive media thanks to the media separated design
- The response times (open and close) can be adjusted separately
- Energy-saving design which ensures a low heating of the medium and, in addition, a long service life
- The risk of water hammer is low, thanks to the dampened closing
- Bürkert design: proven reliability & durability
5282 series
The Bürkert 5282 solenoid valve is used for the most demanding applications. The valve is built to last. The media separation makes the 5282 also suitable for aggressive media. Other interesting features are the standard manual override and adjustable opening and closing times. Furthermore, the circuit function can easily be changed from NC to NO, by simply rotating the 3/2 way pilot valve on top of the main valve body. The 5282 valve is available with a wide variation of housing and sealing materials. The brass housing satisfies all European drinking water requirements. Various ATEX versions are available for potentially explosive environment.
Please note: this product is made to order and can therefore unfortunately not be returned.
Specifications
Connection size : 50 mm
Connection type : Flange
Function : Normally closed
Voltage : 230 V AC
Material : Cast iron
Seal material : EPDM
Operation : Indirect
Recommended for : Water
Min pressure difference (bar) : 1
Max pressure (bar) : 10
Features : Media separation,Adjustable response time,Energy efficient (under 9 VA),Anti-waterhammer
Material quality : Cast iron GG 25 (GJL-250)
Valve bore (mm) : 50
Electrical connection : DIN-A
Nominal power (W) : 8
Valve ports/positions : 2/2 way
Model : Straight
Flange compression class : PN 16
Peak power (W) : 8
Indirect effect : Yes
Explosion safety : None
