Specification:
Class: Industrial
Color: White
Material: Iron, Iron&Steel
Power Source: AC
Is Electric: Yes
Plug Type: US
Voltage: 110V, 60Hz
Power: 550W
Motor: 1/2HP
Needle: 21#/22#/24#
Number of Needles: 1 Operation Mode: Foot Pedal Power Cord Length: 1m/3.3ft Stitch Length: 0-5 mm/0-0.2in
Sewing Speed: 3500 s.p.m Max
Noise: 30db
Type: Industrial Sewing
Presser Foot Lift (by Knee Lifter): 5 mm/0.2in Standard
Lubricating Oil: #10 White Oil
Application: For Materials with Medium Thickness
Table Stand Length: 1.2m/3.93ft
Table Stand Height: 75cm/29.52in
Sewing Machine Length: 60cm/23.62in
Motor:
Package Size: 30*25*25cm/11.8*9.8*9.8in
Gross Weight: 12kg/26.5lbs
Net Weight: 11kg/24.3lbs
Table Stand:
Package Size: 121*50*5cm/47.6*19.7*1.97in
Gross Weight: 22kg/48.5lbs
Net Weight: 20kg/44.1lbs
Sewing Machine:
Package Size: 60*25*50cm/23.6*9.8*19.7in
Gross Weight: 41kg/90.4lbs
Net Weight: 39kg/86lbs
Package Included:
1*Sewing Machine
1*Table Stand
1*Motor
1*Chinese Manual
All Accessories for Assembly
Notes:
In order to prevent mechanical errors or damage, please confirm the following items:
1.Remove the dust accumulated in the transport, check whether the machine has added lubricating oil, if not, please add oil (#10 white oil), it is strictly prohibited to operate and start without oil, otherwise the sewing will be stuck.
2.The direction of rotation of the sewing machine is counterclockwise when standing on the side of the flywheel. Please be careful not to turn the sewing machine in reverse.
3.After receiving the machine, please read the following instructions before use. In particular, threading must be correct. We suggest not using electricity directly after threading. You can manually turn the handwheel to check if it can work normally before using electricity.
4.Please note that the system has been set up at the factory, so do not tap the red and green keys or the system will be disrupted thus causing some malfunctions.
5.Clean the sewing machine before you start using it.
6.Please confirm that the voltage setting is correct. Make sure the power plug is connected correctly.
