JET J-7040-4 460V 3Ph Horizontal Band Saw – JT9-414499

Product Features & specs :

JET J-7040-4 460V 3Ph Horizontal Band Saw

Details

460V 3Ph Horizontal Band Saw – 414499

Features:

• Variable speed drive system allows the operator to fine tune the blade speed fast and easily

• Adjustable blade guides with 6 point contact combination bearing and carbide

• Exclusive swing away control panel

• One piece wheel cover

• Heavy-duty, rugged transmission with hardened and ground gears operating in a oil bath

• Patented 3-jaw rapid action vise

• Cast iron blade wheels

• Coolant system

• 1 in. Bi-metal blade

• Adjustable material stop

What’s Included:

• J-7040-4, 460V 3Ph Horizontal Band Saw – 414499

Cutting Capacity (W x D)

10 in x 16 in

Power Source

Corded

Cutting Capacity – 45 Degrees (Rectangle)

6-1/2 in x 11 in

PreWired Voltage

460V

Cutting Capacity – 90 Degrees (Rectangle)

10 in x 10 in / 7 in x 16 in

Amperage

8

UL Safety

No

Wifi compatibility

No

Blade Width

0.035 in

Bluetooth Compatibility

No

Motor Type

Brushed

Blade Speed (SPM)

100 / 350

Head Movement

45 Degrees

Blade Height

1 in

Blade Wheel Diameter

14 in

Cutting Capacity – 45 Degrees (Round)

10 in

CSA Safety

No

Bed Height

23-1/2 in

Blade Length

130 in

Motor Phase

3

Blade Speed (SFM)

100 – 350

Horsepower

2

Voltage

460V

Cutting Capacity – 90 Degrees (Round)

10 in

Vise Movement

45 Degrees

ETL Safety

No

Length

75.5 in.

Width

33 in.

Height

41 in.

Weight

927 lbs.

Warranty Term

2 Year
