JET J-A3816 115/230V 15 in. 1-Phase 6-Speed Floor Model Drill Press – JT9-354500

Product Features & specs :

JET J-A3816 115/230V 15 in. 1-Phase 6-Speed Floor Model Drill Press

Details

JET’s heavy-duty 6-speed Step Pulley Drill Press are manufactured with the weight and rigidity to maintain the tight tolerances required of metalworking applications. The oversized, massive drill heads have widely spaced bearing surfaces for full quill support throughout its travel. JET included a wider range of operation speeds for drilling both small and larger holes with quick and easy speed changes.

Features:

• 1/2 in. drill chuck and arbor included

• 3 in. column for maximum head support

• 6-spindle speeds from 375 to 5,000 RPM

• Constructed to provide a solid base for drilling

• Larger quill provides greater accuracy.

What’s Included:

• 115/230V 15 in. 1-Phase 6-Speed Floor Model Drill Press – 354500

Power Source

Corded

Drilling Capacity (Cast Iron)

5/8 in

Drilling Capacity (Mild Steel)

1/2 in

PreWired Voltage

115V

UL Safety

No

CSA Safety

No

Wifi compatibility

No

Spindle to Table Distance

25-3/4 in

Bluetooth Compatibility

No

Table Size

15 in x 18 in

Spindle Taper

MT-2

Motor Phase

1

Horsepower

1

Motor Type

Brushed

Voltage

115V/230V

Spindle Speed Range (RPM)

375 / 625 / 1125 / 1950 / 3400 / 5000

No. of T-Slots

2

Column Diameter

5/8 in

Table Capacity (lbs.)

90 lbs

T-Slot Size

1/2 in

ETL Safety

No

No. of Spindle Speeds

6

Length

30 in.

Width

20 in.

Height

71 in.

Weight

394 lbs.

Warranty Term

2 Year
