JET JWDS-2244OSC 115V 15 Amp Variable Speed 22 in. x 44 in. Corded Oscillating Drum Sander with Closed Stand – JT9-723544OSCK

Product Features & specs :

JET JT9-723544OSCK JWDS-2244OSC 115V 15 Amp Variable Speed 22 in. x 44 in. Corded Oscillating Drum Sander with Closed Stand

Details

The newly re-designed 2244 Oscillating drum sander from jet has an exclusive oscillating feature that helps create the best sanding finish with the least amount of dust. When in the oscillating mode, the sanding drum head oscillates from left to right which lowers heat build-up on the sanding belt, reducing loading, and burning. The innovative tool-less parallelism system keeps adjustments simple. The worktable is easily positioned by a turn of the parallelism dial. The Sandsmart conveyor system continuously monitors the load on the drum motor to prevent an overload situation. The mirrored design of the dust hood optimizes dust collection preventing chips and dust from getting between your work-piece and the finish. The jet 2244 Oscillating drum sander delivers everything you need for an effortless finish.

Features:

• Sandsmart control continuously monitors the load on the drum motor and automatically regulates the speed of the conveyor motor to maintain the highest feed rate without overload

• Conveyor bed parallelism is easily adjusted by turning the dial on the outside of the bed – no tools required

• Parallelism adjust dial features a stop to quickly return the conveyor bed to a flat position

• Dust hood includes an integrated channel that mirrors the shape of the drum and directs chips and dust to the 4 in. Collection port

• Precision-machined and dynamically balanced extruded aluminum drum is designed to dissipate heat and protect the work surface from heat-damage

• Die cast drum carriage design is optimized for rigidity to provide years of consistent quality

• Precision-flattened reinforced steel conveyor bed

• Redesigned conveyor system pulls the work piece through the sander instead of pushing

• One rotation of the top-position hand wheel adjusts the drum height by 1/16 in.

• The relative depth scale on the hand wheel allows the user to reset and measure the depth for every project

What’s Included:

• JWDS-2244OSC 115V 15 Amp VS 22″ x 44″ Oscillating Drum Sander – JT9-723544OSCK

Power Source

Corded

Amperage

15

UL Safety

No

Board Thickness (Min.)

1/32 in

Wifi compatibility

No

Conveyor Speed (FPM)

10

Bluetooth Compatibility

No

Board Length (Min.)

2.38 in

Drum Length

23 in

Board Thickness (Max.)

4 in

CSA Safety

Yes

Dust Port Size

4 in

Horsepower

1.75

Voltage

115V

Drum Diameter

5 in

ETL Safety

No

Height

54.31 in.

Weight

216 lbs.

Warranty Term

5 Year
