ProSense temperature sensor, 10K Type 3 thermistor, bolt-on ring, brass sheath, #6 – #10 (4-5mm) screw or bolt size process connection, 6ft 24 AWG wire leads.
Product Attribute Table
Sensor Element : 10K Type 3 thermistor
Sensor Type : Bolt-on ring
Accuracy : +/-0.36 deg F (0.2 deg C)
Sheath Material : Brass
Process Connection : #6 – #10 (4-5mm) screw or bolt size
Electrical Connection : 6ft 24 AWG wire leads
Conductor Insulation Material : PVC
Temperature Sensing Range : -40 to 257 deg F
