The s8vk series single-phase switch mode power supplies are ideal for small control panels. Easy wiring push-in technology can reduce wiring time by up to 60% Simply push the wires in by hand. They are safer than regular screw terminal blocks. The s-type unit is robust and has been coated to protect against harsh environments. Benefits and features You can switch modes. Compact and space-saving
Easy wiring. Just push in.
Built-in control circuit transformer.
Specifications
Voltage type of supply voltage : AC/DC
1st secondary output voltage at DC (V) : 21.6 V to 28 V
Max. output current 1 (A) : 3
Secondary voltage adjustable : Yes
Nominal value output voltage 1 (V) : 24
Nominal value output current 1 (A) : 2.5
Rated voltage AC (V) : 100 V to 240 V
Rated voltage (AC 60 Hz) (V) : 100 V to 240 V
Rated voltage DC (V) : 90 V to 350 V
Electrical connection : Spring clamp connection
Output voltage stabilized : No
Power consumption (VA) : 151.8
Power output (W) : 60
Stabilized : Yes
Short-circuit-proof : Yes
Degree of protection (IP) : IP20
Suitable for safety functions : No
SIL (IEC 61508) : None
Refurbished : No
Modular version : No
Direct mounting possible : No
Wall mounting possible : No
Rail mounting possible : Yes
Performance level (EN ISO 13849-1) : None
Built-in height (mm) : 90
Built-in width (mm) : 32
Degree of protection (NEMA) : Other
Width in number of modular spacings : 1.8
