Lumher PD machine vision lighting, bar light, infrared light emission, plus or minus 30 degrees, 90mm luminous field, continuous, 134 x 42 x 29.5mm housing, 22.8-25.2 VDC operating voltage.
Product Attribute Table
Series : PD
Light Type : Bar light
Light Emission : Infrared
Color Wavelength : 850 nm
Beam Angle : Plus or minus 30 degrees
Luminous Field : 90mm
Housing Size : 134 x 42 x 29.5mm
Body Material : Anodized aluminum
Operation Mode : Continuous
Overdrive : No
Operating Voltage : 22.8-25.2 VDC
Power Rating : 1W
Current Consumption Continuous : 0.04A
IP Rating : IP65
Connection : 4-pin M12 quick-disconnect
