Phoenix Contact STEP DC Power Supply 24V | 2868596

Phoenix Contact STEP DC power supply unit, (wxdxh), 18x61x90mm. 1st Secondary voltage 24V. Voltage type AC/DC. Nominal supply voltage AC 50 Hz 85-240V. output current 10.5A, power output 1W, modular design (rail mount, nominal output voltage 124V).

Specifications

Voltage type of supply voltage : AC
1st secondary output voltage at DC (V) : 24 V to 24 V
2nd secondary output voltage at DC (V) : 24 V to 24 V
Max. output current 1 (A) : 0.5
Max. output current 2 (A) : 0.55
Max. output current 3 (A) : 1
Secondary voltage adjustable : No
Nominal value output voltage 1 (V) : 24
Nominal value output current 1 (A) : 0.5
Rated voltage AC (V) : 100 V to 240 V
Rated voltage (AC 60 Hz) (V) : 100 V to 264 V
Rated voltage DC (V) : 95 V to 250 V
Electrical connection : Screw connection
Output voltage stabilized : Yes
Power consumption (VA) : 37.9
Power output (W) : 12
Stabilized : Yes
Short-circuit-proof : Yes
Degree of protection (IP) : IP20
Suitable for safety functions : Yes
SIL (IEC 61508) : None
Refurbished : No
Modular version : Yes
Direct mounting possible : Yes
Wall mounting possible : Yes
Rail mounting possible : Yes
Performance level (EN ISO 13849-1) : None
Built-in height (mm) : 90
Built-in width (mm) : 18
Degree of protection (NEMA) : Other
Width in number of modular spacings : 1
