Phoenix Contact TRIO-PS DC Power Supply 24V | 2866310

Phoenix Contact TRIO–PS TRIO DC power supply unit, (wxdxh), 40×120.9x130mm. 1st Secondary voltage 24V – 29.5V. Voltage type AC. Nominal supply voltage AC 50Hz 85 – 240V.

Specifications

Voltage type of supply voltage : AC
1st secondary output voltage at DC (V) : 24 V to 29.5 V
2nd secondary output voltage at DC (V) : 22.5 V to 22.5 V
Max. output current 1 (A) : 5
Secondary voltage adjustable : Yes
Nominal value output voltage 1 (V) : 24
Nominal value output current 1 (A) : 5
Rated voltage AC (V) : 85 V to 240 V
Rated voltage (AC 60 Hz) (V) : 100 V to 264 V
Electrical connection : Screw connection
Output voltage stabilized : Yes
Power consumption (VA) : 189
Power output (W) : 120
Stabilized : Yes
Short-circuit-proof : Yes
Degree of protection (IP) : IP20
Suitable for safety functions : Yes
SIL (IEC 61508) : None
Refurbished : No
Modular version : No
Direct mounting possible : No
Wall mounting possible : No
Rail mounting possible : Yes
Performance level (EN ISO 13849-1) : None
Built-in height (mm) : 130
Built-in width (mm) : 40
Degree of protection (NEMA) : Other
Width in number of modular spacings : 2.2
