Key Characteristics For HSS cutters from ø 12 – 44 mm or 1/2″ – 1 3/4″ For HSS cutters in cutting depths of 25 – 55 mm or 1″ – 2 3/16″ Easy angle adjustment Simple alignment to original geometry Laser guided cutter alignment Motor positioning Including CBN grinding wheel
Properties
| Connection | |
|---|---|
| connection 1 model | inside |
| connection 1 size (millimeter) | 19.05 |
| connection 1 type | Weldon |
| connection 2 model | inside |
| connection 2 size (millimeter) | 31.75 |
| connection 2 type | Weldon |
| Dimensions | |
| length (millimeter) | 480 |
| width (millimeter) | 300 |
| height (millimeter) | 320 |
| inside / minimum diameter (millimeter) | 10 |
| outside / maximum diameter (millimeter) | 125 |
| Properties | |
| nett weight (kilogram) | 28 |
| system of measurement | inch (imperial) |
| application | resharpening |
| Performance | |
| rotation speed gear 1 (rotations per minute) | 2800 |
| Supply | |
| motor power (Watt) | 250 |
| power supply frequency (Hertz) | 50 – 60 |
| power supply current | AC |
| power supply connection | US plug according NEMA 5-15 |
| power supply source | mains supply |
| power supply type | electric |
| power supply tension (Volt) | 110 – 120 |
| Other | |
| maximum noise emission (decibel) | 70 |
