Description
The Post Anchor is a fixed, permanent anchor used as a single point anchor or with a horizontal lifeline system. It can be installed on wood, steel or concrete structures.
- Corrosion resistant galvanized coating
- Minimum Breaking Strength: 5,000 lbs
- ANSI Weight Capacity: 130-310 lbs
- OSHA Weight Capacity: Up to 420 lbs
Features
- For use on wood, steel, and concrete decks
- Corrosion resistant galvanized coating
- Permanent anchor
- Can be used as single point anchor or with horizontal lifeline system
Specifications
| Materials | Galvanized steel | Weight | 31.3 lbs (14.2 kg) |
| Baseplate | 16 inch x 16 inch (406 mm x 406 mm) | Height | 14-1/2 inch (368 mm) from baseplate bottom to top of l |
| Minimum Breaking Strength | 5,000 lbs | ANSI Weight Capacity | 130-310 lbs (59-141 kg) |
| OSHA Weight Capacity | Up to 420 lbs (191 kg) | ANSI Standards | Z359.1, A10.32 |
| OSHA Standards | 1926.502, 1910.140, 1910.66 |
