Schneider electric metsect5cc015 current transformer is tropicalized for cable or din rail mount. It has a class 3 accuracy at 5 volts ac, class 0.75 at 3 volts ac and class 1 accuracy at 4 volts ac. This current transformer is rated at class b for electrical insulation and comes with a seal. There are two types of mounting options: clip-on or by-screw. The mounting plate supports the transformer. Metsect5cc015 from Schneider Electric meets many environmental standards, such as vde-0414 and iec61869-2. This particular transformer is 0.19kg in weight and has green premium product sustainab.
Specifications
Primary rated current (A) : 150
Secondary rated apparent power (VA) : 5
Secondary rated current (A) : 5
Secondary connection : Screw connection
Output voltage : No
Over current limiting factor : FS 5
Accuracy class : 0.5
Calibrated : No
Number of primary inputs : 1
Height opening (mm) : 0 mm to 0 mm
Model : Through-feed current converter
Width opening (mm) : 0 mm to 0 mm
With shock protection : No
Contains recycled/recyclable material : No
Opening diameter (mm) : 21
Snap mounting : No
With copper rail : No
