Description
The Simpson Strong-Tie HTT is designed to resist medium tension loads that are fastened with #10 screws. This single-piece formed heavy tension tie has a four-ply formed seat, is designed without rivets and does not require washers. This tension tie provides high-strength, post-pour, concrete-to-steel connections.
- Ideal for retrofit or new construction projects
- Can be installed with cast-in-place or post-installed anchor bolts
- Four-ply formed steel provides increased tension capacity
- Anchor bolt washers not required
Features
- Ideal for retrofit or new construction projects
- Can be installed with cast-in-place or post-installed anchor bolts
- Four-ply formed steel provides increased tension capacity
- Anchor bolt washers not required
- 2-1/2-in. width x 16-in. length
- Anchor rod diameter: 5/8 inch
Specifications
| Width | 2-1/2 inch | Length | 16 inch |
| Anchor rod diameter | 5/8 inch |
Products specifications
| Code Listing | ICC-ES ESR-2523, ICC-ES ESR-2523, ICC-ES ESR-2523 |
| Country of Origin | Varies (subject to change), Varies (subject to change), Varies (subject to change) |
| Finish / Coating | Galvanized (G90), Galvanized (G90), Galvanized (G90) |
| Manufacturer’s Warranty | 25 Year Limited, 25 Year Limited, 25 Year Limited |
| Material | Steel, Steel, Steel |
| Steel Gauge | 12 ga, 12 ga, 12 ga |
