Simpson Strong-Tie MCT1.9X15 MCT 1-9/10-in. x 15-in. Mass Timber Column Tie

• Concealed connection for architectural aesthetics and fire protection
• Universal design allows the same connector to be used on wide range of column sizes
• Simple routing for CNC fabrication of columns
• Integrated lifting hole with tested lifting load values
• Crosshair marks at centerlines of pipe to aid installation
• Recommended for use at column-to-foundation connections in any Seismic Design Category
• Size: 1-9/10 in. x 15 in.
• Electrogalvanized finish

The Simpson Strong-Tie MCT mass timber column tie connects two columns together while allowing the vertical download to be transferred by column-to-column bearing. The MCT can be used on a wide variety of column sizes and is compatible with the Simpson Strong-Tie line of concealed beam hangers (CBH™, ACBH™, SCBH™, HSKP™), making it ideal for use in post-and-beam style construction.

• Concealed connection for architectural aesthetics and fire protection
• Universal design allows the same connector to be used on wide range of column sizes
• Simple routing for CNC fabrication of columns
• Integrated lifting hole with tested lifting load values
• Crosshair marks at centerlines of pipe to aid installation
• Recommended for use at column-to-foundation connections in any Seismic Design Category
• Size: 1-9/10 in. x 15 in.
• Electrogalvanized finish

Install With: (4) 1/2 in. x 4-3/4 in. (min.) dowel or 1/2 in. bolt
