This is a Burkert semi-direct operating 2/2 way solenoid valve with G 1 inch threads and a 42 V AC coil. The valve has a brass housing with EPDM sealing and an orifice size of 25 mm. The circuit function of the solenoid valve is normally closed, which means the valve opens when voltage is applied. As it is semi-direct operating, no pressure differential over the valve is needed to open the valve. Suitable for a pressure range of 0 to 16 bar (232 psi) and a maximum temperature of 120 °C (248 °F). The valve has a Kv-value of 10 m3/h, this translates to a flow rate of 167 l/min at a differential pressure of 1 bar (for water). In imperial units: Cv = 12, which means 12 GPM @ 1 psi pressure drop. For many applications it is enough to select a valve based on the thread size and orifice diameter. For more accurate sizing, use the Kv-value with our easy to use valve sizing calculator. The brass housing is durable, suitable for neutral fluids and resistant to many chemicals. The EPDM (ethylene propylene diene monomer rubber) sealing is suited for neutral fluids and many chemicals, but it has poor resistance to oils and fats. Please note that the internal valve parts, such as the stainless steel plunger and springs, are also in contact with the medium and must be chemically compatible. Consult our chemical resistance chart to verify compatibility of housing and seals with the medium. Suitable for vacuum applications. The valve has an IP65 rating if properly connected.
Pros:
- Suitable for vacuum applications
- Good protection against the environment thanks to the IP65 rating
- Solenoid valves open and close very fast compared to many other valve types
Cons:
- Solenoid valves are very sensitive to dirt and can only be used with clean liquids and gases
- The coil may get hot when energized. A well ventilated environment is recommended
- DIN connector not included
Series:
Please note: this product is made to order and can unfortunately not be returned.
Specifications
Connection size : 1 inch
Connection type : Inner thread cylindrical BSPP-G
Function : Normally closed
Voltage : 42 V AC
Material : Brass
Seal material : EPDM
Operation : Semi-direct
Recommended for : Water,Steam,Alcohols
Max pressure (bar) : 16
Kv value [m3/h] : 10
Features : For vacuum,Coil material insulation class H
Valve bore (mm) : 25
Min temperature (°C) : -30
Max temperature (°C) : 120
Electrical connection : DIN-A
Degree of protection (IP) : IP65
Nominal power (W) : 32
Freq. input voltage (Hz) : 50 Hz to 50 Hz
Valve ports/positions : 2/2 way
Max. ambient temp. (°C) : 55
Actuation : Plunger
Valve construction : Valve complete
QNn value (gas) (l/min) : 10700
Sealing toward outside material : EPDM
Pilot control orifice (mm) : 2
Flow direction : Above seat
Installation length (mm) : 115
