Description
Self-adhering air, vapor, and moisture barrier made from 40-mil rubberized asphalt membrane laminated to cross-laminated film. Forms a tough, flexible seal that won’t shrink, sag, or dry out.
- 40 mils thick
- Self-adhering
- Low permeability
- Flexible at low temperatures
Features
- Low permeability prevents air and moisture vapor transmission
- Provides complete above-grade air, vapor, and water barrier
- Controlled thickness membrane ideal for air barrier applications
- Strong adhesion and puncture resistance
- Easy installation without open flame
Specifications
| Color | White | Thickness | 40 mils (1 mm) |
| Pliability @ -25F (-32C) | No effect | Tensile Strength Film ASTM D412 modified (MD) | 4000 psi (27.6 MPa) |
| Tensile Strength ASTM D882 (MD) | 23.5 lb/in. (4.1 N/mm) | Elongation Film ASTM D412 modified (MD %) | 400 (Typical) |
| Elongation ASTM D882 (MD %) | 400 Min. | Puncture Resistance ASTM E154 | 40 lbf (178 N) Min. |
| Water Vapor Permeance (free film) ASTM E96 Proced | 0.035 Perms | Water Absorption (% by weight) ASTM D1970 | 0.25 Max |
| Water Absorption ASTM D570-81 | 0.1 Max. | Water Penetration ASTM E331 | Pass |
| Application Temperature | 40 degF (4 degC) Min. | Low Temperature Flexibility @ -22F (-30C) (CGSB | PASS |
| Service Temperature | -40 degF to 158 degF | Lap Peel Strength @ 39F (4C) (ASTM D903 180) | 10 lbf/in width (1.75 N/mm) |
| Adhesion to Exterior Gypsum Sheathing CMU Concre | >16 PSI (0.11 MPa) |
