Comelit 316 Simplebus DC power supply unit, (wxdxh), 118x62x93mm. 1st Secondary voltage 29.7V – 36.3V. Voltage type supply voltage DC. Nominal supply voltage at AC 50Hz 88.8 – 264V. Maximum. Output current 1.82A, power output 60W. Modular design (for railmounting).
Specifications
Voltage type of supply voltage : DC
1st secondary output voltage at DC (V) : 29.7 V to 36.3 V
Max. output current 1 (A) : 1.82
Secondary voltage adjustable : No
Nominal value output voltage 1 (V) : 33
Nominal value output current 1 (A) : 0.9
Rated voltage AC (V) : 88 V to 264 V
Rated voltage DC (V) : 31 V to 34 V
Electrical connection : Screw-/spring clamp connection
Output voltage stabilized : No
Power consumption (VA) : 72
Power output (W) : 60
Stabilized : No
Short-circuit-proof : Yes
Degree of protection (IP) : IP20
Suitable for safety functions : No
SIL (IEC 61508) : None
Refurbished : No
Modular version : Yes
Direct mounting possible : Yes
Wall mounting possible : Yes
Rail mounting possible : Yes
Performance level (EN ISO 13849-1) : None
Built-in height (mm) : 93
Built-in width (mm) : 108
Width in number of modular spacings : 7
