UNI-T UT181A Multimeter

The UT181A is a multimeter with the ability to log and plot measured data. In addition to displaying various measurements on the 3.5″ color screen, the meter can also display saved data. True-RMS measurement is offered on the meter, and it is capable of measuring up to 100kHz AC signals. In addition, the water-resistant meter has an IP65-rated housing. You can log up to 20,000 data points and find them easily with the log function. A computer can also be connected to the meter via USB for various functions to be performed via the computer. With the software, you can access all of the meter’s functions, for instance. You can also store large amounts of data this way.

Pros:

• True-RMS can measure sinusoidal and non-sinusoidal AC waveforms.
• Direct logging to a PC

Specifications

Indication : Digital
Our choice for : Multimeter with datalogging,Bluetooth multimeter
Measuring range selection : Automatic
Max. voltage measuring range, AC (V) : 1000
Max. voltage measuring range, DC (V) : 1000
Max. current measuring range, AC (A) : 10
Max. current measuring range, DC (A) : 10
Max. resistance measuring range (MOhm) : 60
Max. temperature measuring range (°C) : 1000
Capacitance measurement : Yes
Max. capacitance measuring range (µF) : 60000
Frequency measurement : Yes
Max. frequency measuring range (kHz) : 60000
Max. voltage measuring circuit category (V) : 600
Degree of protection (IP) : IP65
Relative value measurement : Yes
With conductivity measurement : Yes
Continuity test : Yes
Temperature measurement : Yes
Temperature measurement RTD : No
Temperature measurement TC : No
Data hold : Yes
Max. value storage : Yes
Min. value storage : Yes
Multiple display : No
Resistance test/diode test : Yes
Scaling bar graph lineair : Yes
Scaling bar graph logarithmic : No
True RMS measurement : Yes
With display backlight : Yes
Duty cycle measurements : Yes
Measured value memory : No
Interface : Yes
Bluetooth interface : Yes
Measuring circuit category : CAT IV
Milliohm measurement with 4 wire technique (Kelvin connection) : No
